Ariel - 5FT IP65 Standard Batten

New
Code: ARIEL5FTIP65

Log in to view pricing

Where to Buy

Downloads

  • The Ariel 5FT IP65 Standard Batten is a versatile and energy-efficient lighting solution. It features wattage and colour selectability and has an IP65 rating ensuring that the light is protected against dust and water ingress, making it suitable for a variety of outdoor and indoor settings.

  • • Material - Polycarbonate & Iron body & Stainless Steel clips
    • Shape - Oval

  • Use:

    • Application - Commercial
    • Use - Interior/ Exterior
    • Warranty - 5 Years
    • L70 B50 – 54,000 hours
    • IP Rating - IP65
    • 4 x Wattage Selectable
    • 3 X CCT Selectable
    • 6mm XL terminal block
    • Suspension clips for easier install & maintenance

    Power:
    • Voltage - 220 - 240V
    • Driver - Built-in Boke, non-dimmable
    • Double Insulated - No
    • Operating temp - -20°C to + 45°C
    • Input Frequency - 50/60HZ

    Light output:
    • Lamp Type – Integrated SMD LED
    • Colour Temperature Selectable - 4000K | 5000K | 6500K (factory setting 4000K)
    • Wattage Selectable - 30W/ 40W/ 50W/ 60W (factory setting 60W)
    • Lumens: *(+/-5%)

     Colour Temperature 30W 40W 50W 60W
    4000K 4492 5491 6429 7145
    5000K 4750 5888 6959 7885
    6500K 4503 5509 6424 7204


    • CRI - >80
    • Beam Angle - 120°
    • Dimmable - No

    Product info:
    • Type - LED IP65 Emergency Batten
    • IK Rating - IK08
    • IP Rating - IP65
    • Class I - requires an earth
    • Termination - central rear cable entry pts & 2x end knock pts


    Physical size:
    • Dimensions - 1500L x 92W x 76D


  • • Mounting - Surface
