330Ø Slim Line Button

Code: SLIMB330-3K

Colour Temperature: 3000K
Log in to view pricing

Description

Use:

• Application - Residential use
• Use - Interior & Exterior
• Warranty - 3 year
• L70 - 30,000 hours
• Switching Capacity - 15,000
• IP Rating - IP65
• Operating Temp - -20°C to 50°C

Power:
• Voltage - 230V
• Driver - built in
• Double Insulated - Yes
• Complete with 300mm pre-wired cable attached.

Light output:
• Lamp Type – Integrated LED
• Wattage - 24W
• Lumens - 2000lm or 2200lm
• Colour Temperature - 3000K or 4000K
• CRI - >80
• Beam Angle - 110°
• UGR Rating - <19
• Dimmable - Yes

Product info:
• Type - LED Ceiling Button
• Material - Polycarbonate + Aluminium
• Colour - White
• Shape - Round
• Mounting - Surface mounted or Recessed mounted
• IK Rating - IK04


Physical size:
• Dimensions - 180Ø x 15mm
• Cut-out - 65-155mm
• Adjustable spring clips provide recessed solutions for cut-out sizes: 65Ø-155Ø.



NOTE: THIS MODEL IS SURFACE MOUNT ONLY. CANNOT BE USED WITH RECESSED CLIPS DUE TO WEIGHT.
