Sarah - 4FT Slim 4K LED Batten

Code: SLIMBATTEN36W4K

Colour: White
Log in to view pricing

Where to Buy

Downloads

  • Use:
    • Application - Commercial
    • Use - Interior
    • Warranty - 3 Years
    • L70 – 50,000 hours
    • IP Rating - IP40
    • Operating temp - -20°C > + 50°C

    Power:
    • Voltage - 220 - 240V
    • Driver - Built in
    • Double Insulated - No
    • Power Factor - > 0.95
    • Power Consumption Tolerance - +/-10%
    • Input Frequency - 50/60HZ

    Light output:
    • Lamp Type – Integrated LED
    • Wattage - 36W
    • Lumens - 4200lm
    • Colour Temperature - 4000K
    • CRI - >80
    • Beam Angle - 120°
    • UGR Rating - < 25
    • Dimmable - No

    Product info:
    • Type - LED Batten
    • Material - Aluminium + Iron + PC
    • Optical Cover/Lens Type - Opal
    • Colour – White
    • Mounting - Surface
    • IK rating - IK08


    Physical size:
    • Dimensions - 1200 x 80 x 43

    Product Reference:
    • Catalogue 2021 - Page 41
    • Catalogue 2022 - Page 09

    Flush mount clip system designed to eliminate the gap between the back of each fitting, to the surface they are installed on. By creating flush mounted clips, we can eliminate excess shadowing cast from the body of each fitting. Having a true flush mount clip system with our slim battens creates a clean sleek look when installed/fitted onto flat surfaces.

    Central rear cable entry point was a “must have” feature when creating our slim battens. We have taken install times into consideration to ensure our range of slim battens can be installed efficiently. Each fitting has a recessed channel along back of fitting to provide cable entry along entire fitting, also allowing for excess cable to be hidden.
